Quick Cheat Sheet to All Fish Tank Dimensions


Are you in need of an overview chart that’s referencing the sizes and dimensions of all fish tanks? You may want to bookmark this page.

Here are the dimensions and gallon capacities of all fish tanks:

Aquarium Size Dimensions in Inches
L x W x H
Shape
2.5 Gallon 12.25 x 6.25 x 8.125 Standard Rectangular
5 Gallon 16 x 8 x 10 Standard Rectangular
5.5 Gallon 16.25 x 8.375 x 10.5 Standard Rectangular
10 Gallon Leader 20.25 x 10.5 x 12.6 Standard Rectangular
10 Gallon Long 24.25 x 8.5 x 12.6 Standard Rectangular
15 Gallon 24.5 x 12.5 x 12.75 Standard Rectangular
15 Gallon Tall 20.25 x 10.5 x 18.75 Standard Rectangular
15 Gallon Show 24.25 x 8.5 x 16.6 Standard Rectangular
20 Gallon Tall 24.25 x 12.5 x 16.75 Standard Rectangular
20 Gallon Long 30.25 x 12.5 x 12.75 Standard Rectangular
20 Gallon Extra Tall 20.25 x 10.5 x 23.75 Standard Rectangular
23 Gallon Long 36.25 x 12.625 x 13 Standard Rectangular
25 Gallon 24.25 x 12.5 x 20.75 Standard Rectangular
29 Gallon 30.25 x 12.5 x 18.75 Standard Rectangular
30 Gallon 36.25 x 12.625 x 16.75 Standard Rectangular
30 Gallon Breeder 36.25 x 18.25 x 13 Standard Rectangular
30 Gallon Extra Tall 24.25 x 12.5 x 24.75 Standard Rectangular
33 Gallon Long 48.25 x 12.75 x 13.375 Standard Rectangular
37 Gallon 30.25 x 12.5 x 22.75 Standard Rectangular
38 Gallon 36.25 x 12.625 x 19.75 Standard Rectangular
40 Gallon Breeder 36.25 x 18.25 x 17 Standard Rectangular
40 Gallon Long 48.25 x 12.75 x 16.875 Standard Rectangular
45 Gallon 36.5 x 12.625 x 23.75 Standard Rectangular
45 Gallon Long 48.25 x 12.75 x 19 Standard Rectangular
50 Gallon 36.375 x 18.375 x 19 Standard Rectangular
55 Gallon 48.25 x 12.75 x 21 Standard Rectangular
60 Gallon 48.375 x 12.875 x 23.875 Standard Rectangular
65 Gallon 36.375 x 18.375 x 25 Standard Rectangular
75 Gallon 48.5 x 18.5 x 21.25 Standard Rectangular
80 Gallon Extra Tall 48.875 x 14 x 30.75 Standard Rectangular
90 Gallon 48.5 x 18.5 x 25.375 Standard Rectangular
100 Gallon 72.5 x 18.5 x 19.375 Standard Rectangular
110 Gallon Extra Tall 48.875 x 19 x 30.75 Standard Rectangular
120 Gallon 48.5 x 24.5 x 25.5 Standard Rectangular
125 Gallon 72.5 x 18.5 x 23.375 Standard Rectangular
150 Gallon 72.5 x 18.5 x 29.5 Standard Rectangular
180 Gallon 72.5 x 24.5 x 25.625 Standard Rectangular
210 Gallon 72.5 x 24.5 x 29.625 Standard Rectangular
225 Gallon 72.5 x 27.5 x 27.5 Standard Rectangular

And here are the dimensions of all irregularly-shaped aquarium kits:

Aquarium Kit Dimensions in Inches L x W x H Shape
0.5 Gallon Penn Plax Aqua-ponic 5.875 x 5.875 x 8 Cylinder
1 Gallon Aqueon Frameless 6.375 x 6.375 x 6.375 Cube
1 Gallon Koller Kit 7.5 x 10.5 x 10.2 Pentagon
1 Gallon Koller Hex 7.8 x 7.8 x 8 Hexagon
1 Gallon Koller BettaTank 9 x 9 x 10 Bowl
1 Gallon Koller Deco 15 x 3.8 x 8.5 Half Circle
1 Gallon Aqueon MiniBow LED Kit 8.5 x 6.25 x 9.25 Bow Front
1.4 Gallon Penn Plax Aqua-ponic 7.875 x 7.875 x 10 Cylinder
1.5 Gallon Tetra LED Cube Kit 8.00 x 8.20 x 10.20 Cube
1.5 Gallon Tetra GloFish Kit 7.25 x 8.5 x 11.5 Cube
1.5 Gallon Koller AquaScene 8.5 x 8.5 x 9 Cube
1.5 Gallon Koller BettaView 360 8.1 x 8.1 x 9.8 Cylinder
1.5 Gallon Koller AquaView 9 x 8.2 x 10.8 Half Cylinder
1.5 Gallon Penn Plax Betta Fish Kit 8.5 x 6 x 9.5 Rectangular
1.6 Gallon Koller BettaTank Pedestal 9.5 x 9.5 x 9.5 Bowl
1.7 Gallon Koller BettaTank 9.5 x 9.5 x 11 Bowl
1.7 Gallon Koller AquaScene 8.4 x 8.4 x 11 Hexagon
1.8 Gallon Tetra Waterfall Globe 12 x 10.75 x 13.5 Bowl
2 Gallon Fluval Spec 7.25 x 9.25 x 10 Rectangular
2 Gallon Koller Hex 9.2 x 9.2 x 9.2 Hexagon
2 Gallon Koller AquaView 360 10.2 x 10.2 x 10.5 Cylinder
2 Gallon Koller Gumball 8.5 x 8.5 x 10 Bowl
2 Gallon Penn Plax Prism Nano 7 x 10 x 9 Rectangular
2.5 Gallon Koller AquaView 9.5 x 9.5 x 11.2 Pentagon
2.5 Gallon Koller AquaTunes 9.5 x 9.5 x 11.2 Pentagon
2.5 Gallon Koller AquaTunes 9.5 x 9.5 x 11.2 Cube
2.5 Gallon Aqueon BettaBow LED Kit 11.5 x 7.63 x 12.5 Bow Front
2.5 Gallon Aqueon MiniBow LED Kit 11.5 x 7.63 x 12.5 Bow Front
2.6 Gallon Fluval Spec 10.8 x 11.8 x 8.7 Rectangular
2.65 Gallon Marina 360 10 x 10 x 10 Cylinder
2.7 Gallon Penn Plax Vertex 10 x 9 x 7.75 Cube
3 Gallon Tetra LED Cube Kit 10.3 x 11 x 17.5 Cube
3 Gallon Marineland Silhouette 14.2 x 13.7 x 12.3 Rectangular
3 Gallon Tetra GloFish Kit 14.6 x 8.8 x 11.2 Rectangular
3 Gallon Tetra ColorFusion Half Moon 12.9 x 6.8 x 12.5 Half Cylinder
3 Gallon Marineland Contour Desktop 9.63 x 9.63 x 14 Cube
3 Gallon Tetra Bubbling Half Moon 12.9 x 6.8 x 12.5 Half Cylinder
3 Gallon Tetra GloFish Half Moon 7.5 x 7.5 x 7.7 Half Cylinder
3 Gallon Tetra GloFish Crescent 13 x 7 x 9.5 Bow Front
3 Gallon Aqueon Frameless 9.25 x 9.25 x 9.25 Cube
3 Gallon Koller AquaView 360 10.2 x 10.2 x 14.5 Cylinder
3 Gallon Koller AquaView 14.5 x 10 x 9.2 Flat Back Hexagon
3 Gallon Koller AquaTunes 12.8 x 11.8 x 9 Cylinder
3 Gallon Koller AquaView 11.5 x 11 x 11 Bowl
3 Gallon Marineland Nook Kit 13 x 7.1 x 9.3 Bow Front
3.4 Gallon Penn Plax Water World 10.25 x 7.75 x 11 Rectangular
3.5 Gallon Koller AquaView 11.2 x 8.8 x 13.5 Half Cylinder
3.5 Gallon Koller AquaTunes 11.2 x 8.8 x 13.5 Half Cylinder
3.5 Gallon Koller 11.2 x 8.8 x 13.5 Half Cylinder
4 Gallon biOrb Classic 11.75 x 11.75 x 12.5 Bowl
4 Gallon biOrb Flow 8.19 x 11.81 x 12.4 Rectangular
4 Gallon biOrb Halo 11.81 x 11.81 x 13 Bowl
4 Gallon biOrb Life 11.41 x 7.6 x 16 Rectangular
4 Gallon biOrb Tube 12.91 x 12.91 x 12.4 Cylinder
4.5 Gallon Koller AquaView 14.8 x 10.8 x 13.2 Double Bullnose
5 Gallon Marineland Portrait 11.8 x 11.6 x 17 Cube
5 Gallon Marineland Contour Desktop 9.6 x 9.6 x 19 Cube
5 Gallon Tetra Crescent 16.5 x 11.25 x 13.2 Bow Front
5 Gallon Tetra ColorFusion Bubbling 16 x 8 x 10 Rectangular
5 Gallon Tetra GloFish Glass 16 x 8 x 10 Rectangular
5 Gallon Tetra GloFish Crescent 15.5 x 9 x 11.5 Bow Front
5 Gallon Fluval Chi 10 x 10 x 14.4 Rectangular
5 Gallon Fluval Spec 20.5 x 11.6 x 7.5 Rectangular
5 Gallon Fluval EVO 20.5 x 11.6 x 7.5 Rectangular
5 Gallon Marina Kit 18.5 x 10.8 x 13.3 Rectangular
5 Gallon Koller PanaView 14.2 x 11.5 x 10 Round-edge Rectangular
5 Gallon Aqueon MiniBow LED Kit 14.5 x 10 x 13.5 Bow Front
5 Gallon Aqueon NeoGlow 11.438 x 11.31 x 14.813 Cube
5 Gallon Marineland Nook Kit 15.2 x 5 x 11.25 Bow Front
5 Gallon Marineland Escape 5 14 x 12.5 x 13.5 Hexagon
5 Gallon Penn Plax Water World 13.75 x 8.75 x 11 Rectangular
5 Gallon Penn Plax Vertex 12 x 10.5 x 9.75 Cube
5.5 Gallon Aqueon NeoGlow 16.5 x 8.75 x 10.5 Rectangular
6 Gallon Aqueon Frameless 11.5 x 11.5 x 11.5 Cube
6 Gallon Koller AquaView 360 11 x 11 x 19.8 Cylinder
6 Gallon Aqueon Ascent Frameless 16 x 8.125 x 13.5 Rectangular
6 Gallon Fluval Edge 16.9 x 10.25 x 14 Rectangular
6.5 Gallon Koller 18 x 11 x 13.5 Flat Back Hexagon
7 Gallon Koller AquaView 18.25 x 12.38 x 13.10 Bow Front
7.5 Gallon Aqueon NeoGlow 14.813 x 14 x 13.813 Cube
7.5 Gallon Aqueon Shrimp Kit 13 x 12 x 14 Cube
8 Gallon Aqueon NeoGlow 15 x 13 x 15.25 Hexagon
8 Gallon biOrb Classic 15.75 x 15.75 x 16.5 Bowl
8 Gallon biOrb Cube 12.6 x 12.6 x 13.6 Cube
8 Gallon biOrb Flow 10.23 x 14.96 x 15.35 Rectangular
8 Gallon biOrb Halo 15.75 x 15.75 x 18.11 Bowl
8 Gallon biOrb Life 15.75 x 9.25 x 16.54 Rectangular
8 Gallon biOrb Tube 12.91 x 12.91 x 20.2 Cylinder
8.75 Gallon Aqueon Shrimp Kit 18.25 x 12 x 13 Rectangular
8.8 Gallon Aqueon Aqua Springs 15 x 15 x 14.75 Cube
9 Gallon Fluval Flex 14 x 13 x 13 Vertical Bow Front
9 Gallon biOrb Tube 16.14 x 16.14 x 14.53 Cylinder
10 Gallon Marineland BIO Wheel 20 x 10 x 12 Rectangular
10 Gallon Tetra ColorFusion Bubbling 20 x 10 x 12 Rectangular
10 Gallon Tetra PLAYMOBIL 20 x 10 x 13 Rectangular
10 Gallon Tetra Complete LED 20 x 10 x 12 Rectangular
10 Gallon Tetra Goldfish 20 x 10 x 12 Rectangular
10 Gallon Tetra Half Moon 17.75 x 11 x 17 Half Cylinder
10 Gallon Tetra GloFish Glass 20 x 10 x 12 Rectangular
10 Gallon Aqueon Glass 14.5 x 12.625 x 18.375 Hexagon
10 Gallon Marina Kit 22.6 x 12.6 x 15.3 Rectangular
10 Gallon NUVO Fusion Pro 11.8 x 15 x 13 Cube
10 Gallon Aqueon 20.25 x 10.5 x 15 Rectangular
10 Gallon Aqueon Ascent Frameless 18.75 x 10 x 15.75 Rectangular
10 Gallon Aqueon Hexagon LED Kit 14.5 x 13.375 x 14.75 Hexagon
10 Gallon Aqueon Incandescent LED Kit 22.88 x 12.75 x 13.88 Rectangular
10 Gallon Aqueon NeoGlow 20.5 x 10.5 x 12.5 Rectangular
10 Gallon Penn Plax Water World 17.75 x 11.75 x 12.63 Rectangular
10 Gallon Penn Plax Vertex 13.75 x 13.75 x 13.75 Cube
11 Gallon Aqueon Framless 20.25 x 10.5 x 12.625 Rectangular
11 Gallon Aqueon Frameless 20.25 x 10.5 x 12.625 Rectangular
11 Gallon Aqueon Aqua Springs 15 x 15 x 17.75 Cube
12 Gallon Fluval Edge 17.5 x 10.25 x 22.9 Cube
12 Gallon biOrb Life 14.76 x 10 x 22.04 Rectangular
13.5 Gallon Fluval EVO 22 x 15 x 11.5 Rectangular
14 Gallon Aqueon Frameless 15.125 x 15.125 x 15.125 Cube
14 Gallon NUVO Fusion Pro Peninsula 11.8 x 20 x 13 Rectangular
14.5 Gallon Fluval Flora 15 x 15 x15 Cube
15 Gallon Fuval Flex 16 x 15 x 15 Vertical Bow Front
15 Gallon SeaClear Deluxe 15 x 15 x 20 Hexagon
15 Gallon Aqueon Column 13.75 x 13.75 x 25 Cube
16 Gallon Aqueon 20.25 x 12.875 x 17.75 Bow Front
16 Gallon Fluval Spec 21.8 x 11.5 x 17.5 Rectangular
16 Gallon Aqueon Bow Front LED Kit 20.25 x 12.875 x 20.5 Bow Front
16 Gallon biOrb Classic 19.75 x 19.75 x 20.5 Bowl
16 Gallon biOrb Cube 15.75 x 15.75 x 17 Cube
16 Gallon biOrb Halo 19.66 x 19.66 x 22.83 Bowl
16 Gallon biOrb Life 16.54 x 11 x 24.4 Rectangular
20 Gallon Marineland BIO Wheel 24 x 12 x 16 Rectangular
20 Gallon Tetra Complete LED 24 x 12 x 16 Rectangular
20 Gallon Tetra Goldfish 24 x 12 x 16 Rectangular
20 Gallon Aqueon Glass 18.75 x 16.25 x 20.625 Hexagon
20 Gallon SeaClear Deluxe 15 x 15 x 24 Hexagon
20 Gallon SeaClear 24 x 13 x 16 Rectangular
20 Gallon Marina Kit 26.3 x 15 x 19 Rectangular
20 Gallon NUVO Fusion Pro 23.62 x 15 x 13 Rectangular
20 Gallon NUVO Fusion Pro Peninsula 11.8 x 30 x 13 Rectangular
20 Gallon NUVO Concept Pro Peninsula 15 x 20 x 13 Drop Off Rectangular
20 Gallon NUVO Concept Pro 20 x 15 x 13 Drop Off Rectangular
20 Gallon Aqueon Ascent Frameless 23.75 x 12.625 x 19.75 Rectangular
20 Gallon Aqueon Hexagon LED Kit 18.75 x 16.25 x 23 Hexagon
20 Gallon Marineland Half Moon Combo 23.5 x 12.12 x 23.45 Half Cylinder
21 Gallon Aqueon Framless 24.25 x 12.25 x 16.75 Rectangular
21 Gallon Aqueon Frameless 24.25 x 12.25 x 16.75 Rectangular
25 Gallon NUVO Fusion Pro Lagoon 23.62 x 19.68 x 11.8 Rectangular
25 Gallon NUVO EXT Lagoon 23.6 x 19.7 x 11.8 Cube
26 Gallon Aqueon 24.125 x 14.75 x 20.875 Bow Front
26 Gallon SeaClear 36 x 12 x 16 Flat Back Hexagon
26 Gallon Aqueon Bow Front LED Kit 24.125 x 14.75 x 23.625 Bow Front
28 Gallon Tetra Connect 24 x 15 x 18.9 Bow Front
28 Gallon biOrb Classic 24 x 24 x 25 Bowl
29 Gallon Marineland BIO Wheel 30.25 x 125 x 18.75 Rectangular
29 Gallon Tetra Complete LED 30 x 12 x 18 Rectangular
29 Gallon SeaClear 30 x 12 x 18 Rectangular
30 Gallon Aqueon Framless 30.25 x 12.5 x 18.75 Rectangular
30 Gallon SeaClear 36 x 12 x 16 Rectangular
30 Gallon NUVO Fusion Pro 35.43 x 14.96 x 12.99 Rectangular
30 Gallon NUVO EXT 35.4 x 15 x 13 Rectangular
30 Gallon Aqueon Frameless 30.25 x 12.5 x 18.75 Rectangular
30 Gallon Marineland Half Moon Combo 26.7 x 13.5 x 26.9 Half Cylinder
32.5 Gallon Fluval Flex 32.5 x 15.35 x 15.75 Vertical Bow Front
35 Gallon Aqueon Glass 23.25 x 20.25 x 24.75 Hexagon
35 Gallon Aqueon Hexagon LED Kit 23.25 x 20.25 x 27.125 Hexagon
36 Gallon Aqueon 30.25 x 15.5 x 20.875 Bow Front
36 Gallon Aqueon Bow Front LED Kit 30.25 x 15.5 x 23.625 Bow Front
40 Gallon SeaClear 36 x 12 x 16 Rectangular
40 Gallon NUVO Fusion Pro 23.62 x 19.68 x 18.89 Cube
45 Gallon NUVO EXT 23.6 x 19.7 x 18.9 Cube
46 Gallon Aqueon 36.375 x 16.375 x 20.875 Bow Front
46 Gallon SeaClear 36 x 16.25 x 20 Bow Front
50 Gallon SeaClear 36 x 15 x 20 Rectangular
50 Gallon NUVO Fusion Pro Lagoon 29.92 x 23.62 x 16.14 Rectangular
50 Gallon NUVO EXT Lagoon 30 x 23.6 x 16.1 Rectangular
50 Gallon NUVO INT 23.6 x 23.6 x 19.7 Cube
54 Gallon Aqueon 39 x 27.25 x 23 Corner Bow Front
55 Gallon Marineland BIO Wheel 48.25 x 12.75 x 21 Rectangular
55 Gallon Tetra Complete LED 48 x 13 x 21 Rectangular
60 Gallon NUVO SR Pro 35.43 x 23.62 x 16.14 Rectangular
70 Gallon NUVO INT 23.6 x 35.4 x 55 Drop Off Rectangular
72 Gallon Aqueon 48.375 x 18 x 23 Bow Front
75 Gallon NUVO EXT 35.4 x 23.6 x 19.7 Rectangular
75 Gallon NUVO INT 35.4 x 23.6 x 19.7 Rectangular
90 Gallon NUVO SR Pro 47.24 x 23.62 x 16.14 Rectangular
100 Gallon NUVO EXT 47.3 x 23.6 x 19.7 Rectangular
100 Gallon NUVO INT 47.3 x 23.6 x 19.7 Rectangular
112 Gallon NUVO INT Lagoon 35.4 x 35.4 x 19.7 Cube
150 Gallon NUVO INT Lagoon 47.3 x 35.4 x 19.7 Rectangular
200 Gallon NUVO INT 70.9 x 30 x 21.7 Rectangular
200 Gallon NUVO EXT 70.9 x 30 x 21.7 Rectangular

Getting equipment according to dimensions?

Selecting equipment based on the size of your aquarium is essential for its long-term success.

For one, the dimensions of a fish tank play a huge role in the choice of aquarium lighting because light itself has a limited water penetration.

If you’re in the middle of your research on choosing a suitable light fixture for your aquarium plants you can check my guide on that here. In that link, I do specific product recommendations based on aquarium depth and the type of plants you may want to keep.

The same rules apply for picking adequate grow lights for saltwater reef aquariums. Corals are very sensitive to the intensity and spectrum of the incoming light they use for photosynthesis.

To end up with the right LED light you’ll need to take into account the dimensions of your coral reef aquarium. There are stronger units that penetrate the water well and are suitable for deeper reef tanks and others that are less intense, making a good addition to aquariums with less demanding corals. I made specific recommendations on choosing the best LED lights for corals based on aquarium height and the species you want to keep. Visit the link to learn more.

Choosing the flow rate of a water filter should also be made in conjunction with the gallon capacity of the fish tank. If you keep larger carnivorous fish that produce more waste or you plan to overstock the tank you’d want a stronger filter that turns the water at least 6 times per hour.

For Oscar or Cichlid fish tanks getting an external canister filter makes perfect sense as these units produce more flow and have enormous space for media, which in turn keeps the aquarium clean and safe. I have an article on choosing one according to your fish tank’s gallon capacity (visit the link to learn how to make a choice).

If you want to keep aquatic turtles you should still take into consideration the available water volume in the aquarium. In this case, you can check my article on picking a good filter for a turtle tank according to gallon size. Turtles are messier than most aquatic pets and require a water turn over of at least 8 times the whole aquarium’s gallon capacity per hour.

And last but not least, the gallon capacity of your reef tank, for example, plays a major role in your choice of aquarium wavemaker. You can check my guide on how to make the correct choice by clicking here.

Knowing the exact dimensions of your new fish tank will give you the needed information to make adequate decisions on choosing livestock and the purchase of equipment. Drop me a comment below if you have any questions in those areas and I will answer as soon as I see it.

100.00% of the readers found this article helpful.

Tap a star to leave your vote:

1 Star2 Stars3 Stars4 Stars5 Stars (3 votes, average: 5.00 out of 5)

Loading...

I think you'll also like

Subscribe
Notify of
guest

This site uses Akismet to reduce spam. Learn how your comment data is processed.

0 Comments
Inline Feedbacks
View all comments
